Fiber optic PLC splitters are passive devices that evenly divide a single optical signal into multiple outputs, making them essential for FTTH (Fiber to the Home), PON (Passive Optical Networks), and modern data center deployments. They are compact, reliable, and cost-effective, ensuring efficient signal distribution without requiring external power.

A fiber optic PLC splitter is a passive optical device that splits a single optical signal into multiple signals. It is commonly used in fiber optic networks to distribute optical signals to different destinations. The splitter is designed to divide the light power from the input fiber into multiple output fibers, allowing multiple devices or users to share the same optical signal. Fiber optic PLC splitters come in various types, each suitable for different applications and splitting ratios.

Application:

A fiber optic PLC splitter utilizes the principle of lightwave interference to split the optical signal. It consists of a carefully designed waveguide circuit on a small chip made of silica glass or other materials. The input optical signal is coupled into the chip, where it is split into multiple output signals based on the splitting ratio of the splitter. The splitting ratio determines the proportion of light power that is allocated to each output fiber. Common splitting ratios include 1x2, 1x4, 1x8, 1x16, and 1x32, indicating the number of output fibers. For example, a 1x4 splitter will split the input signal into four equal parts, each delivered through a separate output fiber.

• Available in Rack mount, Modular, LGX, Fan-out or Bare fiber splitter

• Rack mount 19” 1U for 24 ports and 2U for 48 ports and up to 144 ports in 4U

• Made of powder coated cold rolled steel material or ABS

• Integrated with splice cassette and cable management rods

• Compact structure and perfect fiber management

• Suitable for the fusion splice or mechanical splice

• Fiber connector types of FC, SC, ST and LC etc.

• High reliability and reasonable inner space design

• Customer connectors are available upon request

• Singlemode

• Simplex or Duplex adaptors

• Fiber Mode: Singlemode

• Connector type: SC, FC, ST, LC etc.

• Polish Interface Type: PC, UPC, APC

• Insert loss Max: <16.9 dB for 1x32 splitter

• PDL Max: <0.3 dB

• Directivity: 55 dB

• Return Loss Min: 50 (55) dB

• Wide wavelength range 1260nm-1650nm

• Installation Models: Rack mount, Modular, LGX, Fan-out or Bare fiber splitter

• Material: High-quality powder cold rolled steel material or ABS
